Blue Sea A Series Flat Circuit Breaker Switch (20A / Single Pole)

Blue Sea A-Series flat rocker circuit breaker 20A, as used on the Blue Sea 360 panel system (1200 Series) as standard. The flat actuator resists accidental switching by being flush in the ON position. A white actuator indicates OFF position.
Single pole is frequently used for AC or DC Branch circuit protection.
International ON & OFF symbols support vertical or horizontal mounting.

Specifications
• Amperage: 20A AC / 20A DC
• Actuator Style: Flat Rocker
• Poles: 1
• Maximum Voltage: 240V AC / 32V DC
• Circuit Breaker Type: Magnetic Hydraulic - trip free
• Interrupt Capacity: 3000A @ 120V AC // 1500A @ 240V AC // 5000A @ 32V DC
• Minimum Operating Temperature: -40° C
• Maximum Operating Temperature: 85° C
• Mounting Screw: #6-32 Stainless Steel
• Mounting Screw Torque: 6 in-lb (0.68 Nm)
• Screw Terminal Torque: 14 in-lb (1.58 Nm)
• Switching Cycles: 10000
• Terminal Screws: #10-32 Stainless Steel
• Weight: 0.21lb (0.1 kg)

Regulatory: CE marked, TUV certified, CSA certified, UL 1077 recognised.
