Blue Sea A Series Flat Circuit Breaker Switch (10A / Single Pole)

Blue Sea A-Series flat rocker circuit breaker 10A, as used on the Blue Sea 360 panel system (1200 Series) as standard. The flat actuator resists accidental switching by being flush in the ON position. A white actuator indicates OFF position.
Single pole is frequently used for AC or DC Branch circuit protection.
International ON & OFF symbols support vertical or horizontal mounting.
Regulatory: CE marked, TUV certified, CSA certified, UL 1077 recognised

• Switching cycles: 10,000 @ rated A & V
• Type: Magnetic hydraulic -Trip free
• Terminal screw: #10-32 Stainless Steel
• Terminal screw torque: 14-15 in-lb recommended (load terminal is 30° angled)
• Mounting screw: #6-32 Stainless Steel
• Mounting screw torque: 6-8 in-lb recommended
