Blue Sea 285 Panel Mount Circuit Breaker (150A)

Blue Sea 7089 panel mount circuit breaker provides medium duty circuit protection for 150 Amp loads when switching and circuit protection are both required.
- 285 Series
- Trip-free - cannot be held closed after trip
- Visible reset lever shows open condition
- Drop-in replacement for 185-Series Circuit Breakers

Regulatory:
- CE marked
- Meets SAE J1171 external ignition protection requirements, †AIC ratings achieved using SAE J1625
IP67 - protected against immersion up to 1 meter for 30 minutes

Specifications:
Interrupting Capacity: 3000A at 48V DC
Vmxo: 48V DC
Operating Temperature: -40 C min to +85 C max
Type: Thermally Responsive Bi-Metal Blade
Class: Type III Switchable/Manual Reset - Trip Free
Terminal Stud: M6
Terminal Stud torque: 50 in-lb
Mounting: 1/4" Screw
