2000W 24V pure sine wave power inverter 230V AC output (UK sockets)
2000W 24V pure sine wave power inverter 230V AC output (UK sockets)
Couldn't load pickup availability
2000W 24V Pure Sine Wave Power Inverter
230V AC Output | UK Sockets | Off-Grid & Backup Power
The Photonic Universe 2000W 24V Pure Sine Wave Power Inverter is designed to convert 24V DC battery power into stable 230V AC mains electricity. This allows you to power standard UK domestic appliances and sensitive electronics in locations without grid access, such as motorhomes, caravans, boats, or off-grid properties.
With a continuous power output of 2000W and a peak surge capacity of 4000W, this inverter can handle a wide range of loads, including those with electric motors that require higher startup power. Its pure sine wave output ensures compatibility with all AC appliances, providing clean and reliable power.
KEY FUNCTION: Converts 24V DC battery power to stable 230V AC mains electricity for UK appliances.
Key Features
| ▶ 2000W Continuous Power — Reliably runs a wide range of domestic and professional appliances. |
| ▶ 4000W Peak Surge Capacity — Handles high startup loads from motors and inductive devices. |
| ▶ Pure Sine Wave Output — Provides clean, stable power suitable for sensitive electronics and motors. |
| ▶ 24V DC Input — Optimised for 24V battery banks, reducing current and cable thickness. |
| ▶ Integrated UK Sockets — Direct connection for standard British plugs. |
| ▶ USB Charging Port — Convenient 2.1A output for mobile devices. |
Technical Specifications
| Parameter | Value |
|---|---|
| Continuous Power: | 2000W |
| Surge Power: | 4000W |
| DC Input Voltage: | 24V (20-31V DC) |
| AC Output Voltage: | 220-240V AC |
| Output Frequency: | 50-60 Hz |
| Output Waveform: | Pure Sine Wave |
| Total Harmonic Distortion (THD): | <3% |
| Peak Efficiency: | 87% |
| USB Output: | 5V DC, 2.1A |
| Low Battery Alarm: | 23V ± 1V DC |
| Low Battery Shutdown: | 21V ± 1V DC |
| High Voltage Shutdown: | 31V ± 1V DC |
| Dimensions (L x W x H): | 37 x 23 x 11 cm |
| Weight: | 4.9 kg |
Operating & Power Guidance
| Aspect | Guidance |
|---|---|
| Output Type | Pure Sine Wave — Ideal for all AC loads, including sensitive electronics, motors, and inductive appliances. |
| Input Voltage | 24V DC — Designed for 24V battery systems (e.g., two 12V batteries in series). |
| Continuous Load | Up to 2000W — Ensure total appliance wattage does not exceed this for sustained operation. |
| Surge Capability | Up to 4000W — Accommodates momentary power spikes from motors starting. |
| Connection | Direct to 24V Battery Bank — Recommended for optimal performance and safety, avoiding charge controller load terminals. |
Typical Applications
| Application | Description |
|---|---|
| Motorhomes & Caravans | Powering domestic appliances such as TVs, laptops, and small kitchen devices on the go. |
| Boats & Marine Systems | Providing mains power for onboard electronics, navigation equipment, and comforts. |
| Off-Grid Cabins & Sheds | Essential for remote living without grid access, running lights, tools, and entertainment. |
| Backup Power Systems | Running critical appliances during grid outages or accidental power cuts. |
| Field Work & Mobile Workshops | Operating tools and equipment where mains power is unavailable. |
Built-In Protection Functions
This inverter incorporates multiple safety features for reliable operation and protection of your system and appliances. These include over-discharge protection • overload protection • overheating protection • short-circuit protection • high voltage input shutdown • and low voltage input shutdown.
Common Questions
What kind of appliances can this inverter power?
This 2000W pure sine wave inverter can power most standard 230V AC appliances up to its continuous rating, including TVs, laptops, fridges, microwaves, power tools, and lighting. Its pure sine wave output is safe for sensitive electronics.
Why choose a 24V inverter over a 12V model?
A 24V system typically draws half the current for the same power output compared to a 12V system. This allows for thinner cables, reduces voltage drop, and generally leads to a more stable and efficient system, especially for higher power applications like 2000W.
How should I connect this inverter to my solar system?
For optimal performance and safety, connect the inverter directly to your 24V battery bank terminals. Avoid connecting it to the "load" terminals of a solar charge controller, as the inverter's power draw may exceed the controller's capacity.
Does this inverter have UK sockets?
Yes, this model is equipped with standard UK 3-pin sockets, allowing direct connection of British appliances without adapters.
Installation Notes
- Ensure correct DC input voltage (24V nominal) matches your battery bank.
- Use appropriately sized, high-quality DC cables for connection to the battery to minimise voltage drop and heat.
- Install in a dry, well-ventilated area, away from flammable materials and direct sunlight.
- Ensure proper grounding of the inverter as per local electrical regulations.
- Always disconnect battery power before making or breaking connections.
Before You Buy
- Verify your battery bank voltage is 24V DC.
- Calculate the total continuous wattage of all appliances you intend to run simultaneously.
- Consider the surge power requirements of motor-driven appliances (e.g., fridges, pumps).
- Ensure adequate battery capacity to support your desired run times.
- Consult a qualified electrician if unsure about installation or system design.
Please verify all specifications and compatibility requirements before purchase. Product specifications are subject to change by the manufacturer. A 1-year manufacturer warranty is typically provided.
